Large Manhole Cover

SD400 – A Large Well Cover for Remediation

The SD400 Cover is designed mainly for remediation work where bulky equipment may need to be around the well head. This large cover with a hinged lid offers wide access, with an easy lid opening. It can be ordered with or without a sheet metal skirt fitted.

  • 600mm diameter opening
  • 850mm overall diameter
  • All ductile iron cast construction with sheet metal skirt (500mm long)
  • Hinged lid requires only 1 key to lift up
  • Designed to be cemented into the ground flush
  • 40 ton load rating



Description

The manhole cover  is a large heavy duty access cover designed with remediation applications in mind.
Hinged, this will allow a single person to lift the lid, using a key.



SD400RDSKManhole cover, Round, Cast iron, 600 x 600mm inside dims, Hinged lid, with 500mm skirt, Req 1 key to open
SD400RDManhole cover, Round, Cast iron, 600 x 600mm inside dims, Hinged lid, *No Skirt, Req 1 key to open
SD400KeyManhole cover Key, Fits D400 covers
