Sand and Gravel
Fieldtech Solutions’ range of Premiun Graded Sand and Gravel is produced from water washed high purity silica. Dry screening ensures excellent control of Particle Size Distribution.
The sand & gravel is tested and controlled to rigorous standards which ensure consistent physical properties resulting in predictable and repeatable performance. Sibelco Australia actively manages a Quality Management System certified to ISO9001:2008. High quality Gravel typically finds use in applications such as water filtration, drilling and flooring. The following typical properties may help you to determine the product which will best suit your application.
- Details
- Ordering Information
For more information on sizes of the Premium Graded Sand, and Premium Graded Gravel please refer to the table below
SAND
Patricle size Analysis - Sand
Mean values, These do not represent A Specification
| Particle size Analysis | | Premium Graded Sand | |
| Mesh Size
| | |
| mm | BSS | 8/16 |
| 2.8
| | 0.1 |
| 2.36 | 7 | 1.7 |
| Typical Mean % Retained on Individual Sieves | 2.00 | 8 | 13.0 |
| 1.7 | 10 | 19.0 |
| 1.4 | 12 | 33.5 |
| 1.18 | 14 | 25.9 |
| 1.00 | 16 | 5.9 |
| PAN | | 0.9 |
GRAVEL
Particle Size Distribution for Gravel
Mean Values. These Do Not Represent A Specification
| MESH SIZE | | |
| mm | BSS | 6/3 |
| 6.7 | | 0.6 |
| 5.6 | 3 | 7.3 |
| 4.75 | 3 1/2
| 13.5 |
Typical Mean
% retained on Individual Sieves | 4.0 | | 26.9 |
| 3.35 | 5 | 28.5 |
| 2.8 | | 18.9 |
| 2.36 | 7 | |
| 2.0 | 8 | |
| GRA166-3LA |
Gravel, 6/3 grade, 25kg bag, (40 bags per pallet) |
| SWD8/16 |
Sand, washed & dried, 8/16 grade, 25kg bag, 1-2mm range |
